ECA Brass Spring-Loaded Foot Valve 1 1/2″ PN10 601007020
Keeps pump suction lines primed by blocking reverse flow automatically.
The ECA Brass Spring-Loaded Foot Valve 1 1/2″ PN10 601007020 is a control element that prevents backflow in liquid systems, featuring a high-quality brass body and a durable spring mechanism. In addition, its design focuses on stopping water from escaping back in pump and suction lines. Consequently, it is preferred for its long service life and reliable performance.
This valve opens or closes automatically according to the flow direction in the system. When the pump runs, the spring-supported disc opens and allows liquid to pass. Moreover, when the pump stops, the spring force closes the disc automatically and blocks reverse flow. As a result, this principle helps maintain system pressure and prevents pumps from running dry. The body is brass, the seal is NBR, the spring is stainless steel, and the connection is female x female. It is rated PN10 with a maximum working temperature of +90°C and complies with TS EN ISO 228-1.
ECA Brass Spring-Loaded Foot Valve — Technical Specifications
It is used in pump suction lines, drilling and well systems, water tanks and reservoirs, and garden and agricultural irrigation systems. Furthermore, it serves in fire suppression systems, booster systems, and industrial process lines. Therefore, it is a suitable choice for both industrial and individual applications.
Key Advantages
- Prevents backflow to protect pumps from dry running
- Automatic spring-loaded operation requires no external power
- Durable brass body and stainless steel spring for long service life
- NBR seal compatible with water and neutral liquids
- PN10 pressure rating and +90°C temperature limit for diverse systems
Applications
- Pump suction lines
- Drilling and well systems
- Water tanks and reservoirs
- Garden and agricultural irrigation
- Fire suppression systems
- Booster systems
- Industrial process lines
The ECA Brass Spring-Loaded Foot Valve 1 1/2″ PN10 enhances system safety and performance, delivering reliable results for both industrial and individual use. ORFA supplies worldwide and provides technical support.
ORFA INDUSTRIAL PRODUCTS INDUSTRY AND TRADE INC.
Your Reliable Partner in Industrial Flow Technologies
