AYVAZ KV-4 Gear Operated Lug Type Butterfly Valve DN500
Reliable large-diameter flow control with minimal maintenance.
AYVAZ KV-4 Butterfly Valve DN500 delivers reliable and efficient flow control in industrial plants. In addition, its compact structure simplifies installation. Moreover, the gearbox mechanism enables precise opening and closing, particularly in large-diameter lines.
The valve operates with minimal pressure loss due to its sealing performance. Furthermore, the GG25 cast iron body and AISI316 stainless steel disc offer superior corrosion resistance. Therefore, the DN500 nominal diameter allows effective control even in high-flow systems, safely regulating fluid passage in fully open or fully closed positions. The shaft is SS420 for DN25–DN300 and SS431 for DN350–DN600. Horizontal mounting is recommended for DN300 and above. Maximum operating temperature is 130°C, and the elastomer seal means no additional gasket is required on the pipe flange.
AYVAZ KV-4 Butterfly Valve — Technical Specifications
This valve is widely used in HVAC systems, water treatment plants, and firefighting lines. In addition, it is safely preferred in shipbuilding and marine industries for seawater lines. Consequently, it provides durability in demanding process conditions.
Key Advantages
- High corrosion resistance from GG25 cast iron body and AISI316 stainless steel disc
- Gear actuator enables easy operation even at large diameters like DN500
- Elastomer sealing system minimizes maintenance and extends service life
Applications
- Heating, ventilation, and air conditioning (HVAC) systems
- Water treatment plants and distribution networks
- Firefighting systems and shipbuilding lines
In summary, the AYVAZ KV-4 Butterfly Valve DN500 offers a reliable and long-lasting solution for industrial facilities. ORFA Industrial has supplied this product as an authorized distributor since 1985. ORFA supplies worldwide and provides technical support for orders and inquiries.
ORFA INDUSTRIAL PRODUCTS INDUSTRY AND TRADE INC.
Your Reliable Partner in Industrial Flow Technologies
