AYVAZ KV-4 Gear Operated Lug Type Butterfly Valve DN25
Precise, low-torque on-off control with long service life in demanding lines.
AYVAZ KV-4 Lug Type Butterfly Valve DN25 delivers precise on-off operation through its gear-operated actuator. In addition, its compact design simplifies installation and flow control. Moreover, the GG25 cast iron body and AISI316 stainless steel disc provide superior corrosion resistance.
The valve controls fluid passage by rotating the disc around its own axis. Sealing occurs between the metal disc and the elastomer seat that lines the body, ensuring tight shutoff. Therefore, it achieves effective control with minimal pressure loss in fully open or fully closed positions. For DN300 and larger, horizontal mounting is recommended. The shaft is SS420 for DN25–DN300 and SS431 for DN350–DN600, with a maximum operating temperature of 130°C.
AYVAZ KV-4 Lug Type Butterfly Valve — Technical Specifications
It is widely preferred in HVAC systems, water treatment plants, and firefighting lines. Furthermore, it is safely used in the food and chemical industries as well as shipbuilding. In addition, it provides an effective solution in mining and drilling applications. Consequently, low maintenance requirements support long-lasting performance across these sectors.
Key Advantages
- Gear-operated actuator enables precise, low-torque on-off control
- AISI316 stainless steel disc and GG25 cast iron body ensure long-lasting durability
- Elastomer seat provides high sealing performance and minimizes maintenance
Applications
- Heating, ventilation, and air conditioning (HVAC) systems
- Water treatment plants and distribution networks
- Firefighting systems, shipbuilding, and mining industry applications
In conclusion, the AYVAZ KV-4 Lug Type Butterfly Valve DN25 is a reliable, long-lasting valve solution for DN25 industrial facilities. ORFA Industrial has supplied this product as an authorized distributor since 1985. In addition, ORFA supplies worldwide and provides technical support and pricing information upon request.
ORFA INDUSTRIAL PRODUCTS INDUSTRY AND TRADE INC.
Your Reliable Partner in Industrial Flow Technologies
