KSB Etanorm 100-080-250 Centrifugal Pump 4 kW 1450 rpm
High-efficiency fluid transfer for continuous industrial duty.
The KSB Etanorm 100-080-250 Centrifugal Pump 4 kW 1450 d/d is a reliable fluid transfer solution for industrial processes. In addition, it delivers a maximum flow of 105 m³/h with a 16 mSS discharge head. Furthermore, the grey cast iron JL1040 casing and E335 steel impeller ensure a long service life.
A single mechanical seal according to EN 12756 improves sealing performance. Moreover, the IE3 premium efficiency motor operates within a voltage range of 3 x 380 V AC -15% to 480 V AC +10% and draws a maximum current of 8.6 A. As a result, energy consumption is optimized. In addition, the IP55 motor protection resists dust and water. The back pull-out design allows easy removal of the coupling and impeller without disturbing pipe connections.
KSB Etanorm 100-080-250 Centrifugal Pump — Technical Specifications
These pumps are preferred in industrial process lines, drinking water transfer systems, and HVAC applications. Furthermore, they play an effective role in agricultural irrigation and drainage projects. Consequently, the wide liquid temperature range and maximum working pressure of 16 bar offer flexibility across different sectors. Moreover, the integrated base plate provides vibration-free installation.
Key Advantages
- Replaceable casing wear rings provide long life and low maintenance cost
- Closed radial impeller with multi-curved vanes ensures high hydraulic efficiency
- Back pull-out design minimizes plant downtime
Applications
- Liquid transfer in industrial process lines and chemical plants
- Reliable flow in drinking water and service water distribution systems
- Circulation pump in heating, cooling, and HVAC systems
In conclusion, the KSB Etanorm 100-080-250 Centrifugal Pump 4 kW 1450 d/d is ideal for critical applications thanks to its low maintenance need and energy savings. ORFA Industrial supplies worldwide and provides technical support and quotations for industrial flow requirements.
