WINPO WNP 10-H Hydromat

WINPO WNP 10-H Hydromat

Extend pump life with reliable automatic control and built-in dry-run protection.

WINPO WNP 10-H Hydromat is a reliable automatic control and protection solution for single-phase pump systems. In addition, it starts and stops pumps automatically, therefore extending pump life through dry-run protection.

This device operates on 220-240V, 50/60Hz supply with an optional 110-120V or 110-240V dual voltage version. It handles a maximum power of 1.1 kW (1.5 HP) and a maximum current of 10A. Start pressure is selectable at 1.2, 1.5, or 2.2 bar, with an adjustable pressure range of 1.2 to 3.0 bar. Maximum working pressure is 10 bar (1.0 MPa), and it withstands temperatures up to 55°C. The connection size is R 1 inch threaded, and the IP65 rating ensures full protection against dust and water. Programming functions include 10-second automatic stop, 10-second dry-run protection, 10-second forced start, and manual operation via reset button.

WINPO WNP 10-H Hydromat — Technical Specifications

This hydromat is widely used in domestic booster systems and garden irrigation installations. Moreover, it is preferred in water pressurization units of industrial buildings. It also provides safety against dry-run in small-scale water supply systems, consequently offering full control and protection in pump systems.

In conclusion, WINPO WNP 10-H Hydromat provides reliable automatic control and protection for your pump systems. ORFA Industrial supplies worldwide and provides technical support as an authorized distributor since 1985. Therefore, do not hesitate to contact our expert team for your needs.
