VALFTEK Metal Bellows Valve DN150 PN16

VALFTEK Metal Bellows Valve DN150 PN16

Zero-leak shutoff for high-temperature steam and thermal oil lines.

VALFTEK Metal Bellows Valve DN150 PN16 is engineered for safe control of high-temperature fluids such as steam and thermal oil. In addition, its cast iron body and metal bellows combination allows reliable service from -10°C to +400°C. Moreover, the flanged connection type integrates quickly into existing pipework.

The valve meets DIN EN 12266-1 Class A sealing, so leakage stays at zero across the operating range. A manual handwheel gives the operator immediate mechanical action, and as a result no software dependency exists. The nominal diameter is DN150 with a PN16 pressure class, and the applicable media include steam, thermal oil, hot water and mildly aggressive chemicals.

VALFTEK Metal Bellows Valve — Technical Specifications

Petrochemical plants use this valve on steam and thermal oil headers, and energy stations rely on it for boiler and heating circuits. Furthermore, a stainless steel option supports hygienic process lines in food and pharmaceutical production. Every unit passes factory quality control under a zero-defect principle, therefore long service life is assured in demanding environments.

In summary, VALFTEK Metal Bellows Valve provides maximum safety and tightness in industrial facilities. ORFA Industrial supplies this product worldwide as an authorized distributor since 1985 and provides technical support.
