TDS Manifold with Integral Valve 6 Outlets 1”
Precise flow balancing for multi-zone heating and cooling circuits.
The TDS Manifold with Integral Valve 6 Outlets provides an integrated flow control solution for six independent circuits. In addition, each outlet features a solid brass tower valve with excellent sealing performance under high pressure. Furthermore, the compact body saves space and shortens installation time.
The manifold is constructed from a corrosion-resistant brass alloy, reducing maintenance over many years. Its 1” (25 mm) BSP threaded connections integrate with standard pipework. Moreover, the blue body marks cold water or return lines for easy system identification. It operates at a maximum pressure of 10 bar (PN10) and a maximum temperature of 90°C, conforming to EN 12098 / DIN EN 12098-5.
TDS Manifold with Integral Valve 6 Outlets — Technical Specifications
This manifold is commonly used in central heating panels for hotels, hospitals, and commercial complexes. In addition, it balances flow in multi-zone cooling applications, connecting parallel to radiator and fan-coil systems. Consequently, it integrates easily into existing installations during retrofit projects.
Key Advantages
- Independent valve on each circuit for precise flow adjustment and balancing
- Compact six-outlet body saves space and simplifies installation
- Brass alloy construction resists corrosion and extends service life
Applications
- Flow control in central heating return lines
- Balanced distribution in multi-zone cooling systems
- Heating panels for hotels, hospitals and commercial buildings
In conclusion, the TDS Manifold with Integral Valve 6 Outlets is an ideal choice for reliable flow management in your installation. ORFA Industrial has stocked this product as an authorised distributor since 1985. ORFA supplies worldwide and provides technical support; contact us for pricing and technical assistance.
