PEDROLLO TOP 3 VORTEX/GM Submersible Pump 0.75 HP
Reliable dirty water evacuation for narrow spaces and industrial facilities.
PEDROLLO TOP 3 Submersible Pump is a professional solution for reliable dirty water evacuation in narrow spaces such as elevator pits and pump wells. In addition, its vortex impeller technology processes solid particles up to 20 mm in diameter without clogging. Moreover, the compact vertical float design enables easy installation. Consequently, it provides dependable performance in industrial facilities.
This submersible pump operates on a 220 Volt single-phase power supply with a 0.75 HP (0.55 kW) motor. Furthermore, it achieves a maximum head of 8.5 meters and a maximum flow rate of 10.8 m³/h (180 l/min). The pump body is made of AISI 304 stainless steel, while the motor shaft is AISI 431 stainless steel. In addition, the carbon-ceramic mechanical seal offers excellent corrosion resistance. The integrated cooling system protects the motor during low-level operation, and the liquid temperature range is +5°C to +40°C.
PEDROLLO TOP 3 Submersible Pump — Technical Specifications
This pump effectively evacuates grey water and dirty water from building storage tanks. In particular, it provides a reliable solution for conveying liquids with solid particles in industrial facilities. Furthermore, it is preferred for farm and agricultural wastewater applications. As a result, it suits elevator pits, pump wells, and industrial plants.
Key Advantages
- Vortex impeller technology prevents clogging on solid particles
- Compact vertical float design adapts to narrow spaces
- AISI 304 stainless steel body resists acidic water
Applications
- Elevator pits and pump well evacuation systems
- Grey water and dirty water storage tank evacuation in buildings
- Conveying liquids with solid particles in industrial facilities
In conclusion, PEDROLLO TOP 3 Submersible Pump offers a reliable and efficient solution for dirty water evacuation. ORFA Industrial has been your trusted partner in industrial flow technologies since 1985. ORFA supplies worldwide and provides technical support; contact our expert team for assistance.
ORFA INDUSTRIAL PRODUCTS INDUSTRY AND TRADE INC.
Your Reliable Partner in Industrial Flow Technologies
