Pedrollo RXm 5 Stainless Steel Submersible Drainage Pump 1.5 HP

Original price was: $1,379.82.Current price is: $938.27.

The Pedrollo RXm 5 is a submersible drainage pump with a 1.5 HP motor, AISI 304 stainless steel construction, and a 1 1/2″ threaded outlet. It delivers up to 18 m³/h and a maximum head of 20 mSS for industrial and domestic dewatering.

Availability: In stock

SKU: 1276880050520660000800108 Category: Brand:
INDUSTRIAL DRAINAGE / DEWATERING EQUIPMENT

Pedrollo RXm 5 Stainless Steel Submersible Drainage Pump 1.5 HP

Reliable high-capacity drainage with superior corrosion resistance for demanding industrial and domestic sites.

Pedrollo RXm 5 Submersible Drainage Pump offers a professional solution for high-capacity liquid removal with its AISI 304 stainless steel construction. In addition, its 1.5 HP motor delivers 18 m³/h flow rate and 20 mSS head. Moreover, the fully AISI 304 stainless steel body provides superior corrosion resistance, and the food-compatible material allows safe operation in olive oil and brine transfer.

This pump features a double shaft seal and a thermally protected motor for continuous performance. Furthermore, the 10-metre cable and 10-metre maximum immersion depth allow flexible use in industrial sites. In addition, the 1 1/2″ threaded outlet enables quick installation, therefore increasing operational efficiency.

Pedrollo RXm 5 Submersible Drainage Pump — Technical Specifications

Material
AISI 304 Stainless Steel
Motor Power
1.1 kW / 1.5 HP – 220V
Maximum Flow Rate
18.0 m³/h
Maximum Head
20 mSS
Connection Size
1 1/2″ Threaded
Cable Length
10 metres
Maximum Immersion Depth
10 metres
Protection
Thermal Protection, Double Shaft Seal
Performance Data (Q/H)
0 m³/h → 20 mSS, 3.6 m³/h → 17.5 mSS, 6.0 m³/h → 15.5 mSS, 9.6 m³/h → 12.5 mSS, 12.0 m³/h → 10.0 mSS, 15.6 m³/h → 7.0 mSS, 18.0 m³/h → 5.0 mSS

This pump efficiently drains flooded garages, basements, and elevator pits. In particular, it is preferred for olive oil and brine transfer in the food industry; moreover, it delivers high performance when drawing clean water from wells and cisterns. Furthermore, its long-lasting construction makes it ideal for domestic wastewater and rainwater accumulation removal.

Key Advantages

  • Complete AISI 304 stainless steel construction for maximum corrosion resistance
  • 1.5 HP motor and 18 m³/h flow rate for high-capacity liquid removal
  • Double shaft seal and thermal protection ensure uninterrupted and safe operation

Applications

  • Rapid drainage of flooded garages, basements, and elevator pits
  • Olive oil and brine transfer in the food industry
  • Clean water extraction from wells and cisterns, and domestic wastewater drainage

In conclusion, the Pedrollo RXm 5 Submersible Drainage Pump is the ideal choice for those seeking a reliable drainage solution in industrial and domestic sites. ORFA Industrial has supplied it as an authorised distributor since 1985, and now ORFA supplies worldwide and provides technical support.
