PAKKENS Bottom Connection Dry Type Pressure Gauge Ø63 mm 10 Bar 1/4”

PAKKENS Bottom Connection Dry Type Pressure Gauge Ø63 mm 10 Bar 1/4”

Durable, clearly readable pressure monitoring for compressor and pump lines.

PAKKENS Bottom Connection Dry Type Pressure Gauge Ø63 mm 10 Bar provides a reliable choice for pressure monitoring in industrial facilities. In addition, its 63 mm polycarbonate case and brass internal mechanism deliver effective corrosion resistance. Consequently, it works with liquids and gases that do not corrode copper alloys.

The CL 2,5 accuracy class provides sufficient precision for standard industrial applications. Moreover, the device operates within a 10 bar full-scale range and maintains measurement accuracy between 75% and 100% of the scale. The 1/4 inch NPT threaded bottom connection brings fast integration to process connection points. Furthermore, the IP41 protection rating guards against dust and water splashes, so safe operation is possible at a maximum liquid temperature of +60°C.

PAKKENS Bottom Connection Dry Type Pressure Gauge — Technical Specifications

This pressure gauge is frequently preferred in water pump, booster and air compressor lines. In particular, it increases system safety in industrial boilers and compressed air installations. Additionally, it is ideal for pressure tracking in agricultural irrigation equipment and open tank pumps. Moreover, the polycarbonate dial cover and aluminium scale allow operators to read pressure values clearly.

In conclusion, the PAKKENS Bottom Connection Dry Type Pressure Gauge Ø63 mm 10 Bar ensures safe and precise pressure management in your industrial installation. ORFA Industrial supplies worldwide and provides technical support as an authorised distributor since 1985. Contact us for technical support and orders.
