MAXTOR Intermediate Leg Tee 10 – 1/4″
Precise 10-degree positioning with durable, low-maintenance performance.
MAXTOR Intermediate Leg TE 10 – 1/4″ is the ideal pneumatic solution for precise positioning and durable performance. In addition, it limits the movement of rotary actuators to a 10-degree angle. Moreover, its aluminum body structure offers superior resistance to corrosion. Consequently, it stands out as a reliable component in pneumatic automation lines. Furthermore, the 1/4 inch BSP connection port allows easy integration with standard equipment. Therefore, production in accordance with the ISO 4401 standard guarantees industrial compatibility. In addition, a maximum working pressure of 10 bar and a temperature range of -10°C to +60°C deliver stable performance under demanding conditions. As a result, a low friction coefficient achieves a fast response time.
The aluminum body combines a lightweight structure with high mechanical strength. The 10-degree angle value restricts rotary actuator travel for accurate end-position control. Furthermore, the 1/4 inch BSP connection type ensures a leak-tight seal with standard fittings. The unit can be mounted in any position, which simplifies installation in compact assemblies. Additionally, the low friction coefficient supports quick reaction times and reduces air consumption. Therefore, system safety and efficiency increase noticeably.
MAXTOR Intermediate Leg TE 10 — Technical Specifications
This intermediate leg is widely used in automotive assembly lines, textile machinery, and packaging systems. Moreover, its compact structure allows mounting in tight spaces inside pneumatic automation panels. In particular, the maintenance-free design lowers operating costs over the service life. Furthermore, every unit passes strict quality controls before shipment. Consequently, it delivers reliable positioning and angle limitation in demanding production environments.
Key Advantages
- Precise 10-degree angle control for exact positioning of rotary actuators
- Aluminum body for a lightweight structure and superior corrosion resistance
- Maintenance-free design for long service life and low operating costs
Applications
- Rotary actuator control in automotive assembly lines
- Precise positioning and angle limitation in textile machinery
- Packaging systems and pneumatic automation panels
In conclusion, MAXTOR Intermediate Leg TE 10 – 1/4″ provides precise control and durability for your pneumatic projects. ORFA Industrial has stocked this product as an authorized distributor since 1985. ORFA supplies worldwide and provides technical support, so contact us for assistance and fast delivery.
ORFA INDUSTRIAL PRODUCTS INDUSTRY AND TRADE INC.
Your Reliable Partner in Industrial Flow Technologies
