AYVAZ KV-4 Gear Operated Lug Type Butterfly Valve DN80
Compact, low-maintenance shutoff with precise gear-operated control for medium-sized lines.
The AYVAZ KV-4 Lug Type Butterfly Valve delivers reliable fluid control in industrial plants. In addition, its GG25 cast iron body and AISI316 stainless steel disc provide high corrosion resistance. Therefore, the DN80 nominal diameter performs effectively in medium-sized pipelines.
The disc rotates around a vertical axis to regulate fluid passage. Moreover, the elastomer gasket seals against the pipe flange, so pressure loss stays minimal in fully open or closed positions. The valve tolerates temperatures up to 130°C. The stem is SS420 for DN25–DN300 and SS431 for DN350–DN600. Horizontal mounting is recommended for DN300 and above.
AYVAZ KV-4 Lug Type Butterfly Valve — Technical Specifications
This valve serves HVAC heating and cooling circuits. Furthermore, it is preferred in water treatment plants, mining and drilling applications. In particular, it works safely in shipbuilding, marine, food and chemical industries. It also provides an effective solution in water and air lines of fire extinguishing systems.
Key Advantages
- GG25 cast iron body for high mechanical strength and corrosion resistance
- Gear actuator enables precise, low-effort open-close control
- Elastomer gasket ensures tight sealing and long-lasting, low-maintenance service
Applications
- HVAC heating, ventilation and air conditioning systems
- Water treatment plants and distribution networks
- Fire extinguishing systems and industrial process lines
As a result, the AYVAZ KV-4 Lug Type Butterfly Valve provides reliable flow control in industrial facilities. Consequently, ORFA Industrial supplies it worldwide as an authorized distributor since 1985 and provides technical support.
