AYVAZ KV-4 Gear Operated Lug Type Butterfly Valve DN600

AYVAZ KV-4 Gear Operated Lug Type Butterfly Valve DN600

Gear-operated large-diameter flow control with dependable sealing and low operating effort.

The AYVAZ KV-4 Lug Type Butterfly Valve DN600 provides a strong flow control solution for industrial plants. In addition, its gear-operated actuator allows precise, low-effort use even on large-diameter valves. It stands out with high sealing performance, particularly in water, gas and wastewater lines. Furthermore, its compact body saves installation space.

The working principle relies on a disc rotating around the shaft to regulate fluid passage. Moreover, the elastomer seat also performs the sealing duty on the pipe flange. As a result, this design delivers high efficiency with minimum pressure loss in the fully open position. Consequently, energy losses in the system decrease and long service life is achieved. Body material is GG25 cast iron in lug type; the shaft is SS420 for DN25–DN300 and SS431 for DN350–DN600. Mounting is recommended in the horizontal position for DN300 and above.

AYVAZ KV-4 Lug Type Butterfly Valve — Technical Specifications

This butterfly valve serves a wide range of uses, from HVAC systems to firefighting lines. In particular, it is reliably preferred in water treatment plants and shipbuilding. Additionally, it provides hygienic flow control in the food and chemical industries. In this context, it works compatibly with different fluids such as seawater, gas and air.

In conclusion, the AYVAZ KV-4 Lug Type Butterfly Valve DN600 offers a reliable, long-lasting flow control solution for industrial plants. ORFA Industrial has supplied this product with technical support as an authorised distributor since 1985. Moreover, we provide mounting and maintenance consultancy tailored to your needs. ORFA supplies worldwide and provides technical support.
