ARI® SAFE P 35.921 Proportional Lift Safety Valve PN40 DN32
Staged discharge prevents pressure shocks and protects high-pressure systems reliably.
ARI SAFE P 35.921 Safety Valve delivers reliable overpressure protection for steam and gas lines. In addition, its proportional lift principle opens gradually once system pressure exceeds the permitted value, therefore preventing sudden shocks. It is particularly preferred in industrial plants operating under high temperature and pressure.
The body is made of 1.0619+N cast steel, while the bonnet consists of EN-JS1049 ductile iron. Moreover, the internal parts are manufactured from 1.4021+QT stainless steel; the seat and disc are made from 1.4571 (AISI 316Ti) and 1.4122 (AISI 420) stainless steel respectively. As a result, high corrosion resistance and long service life are ensured. Furthermore, the spring material is FDSiCr/51CrV4, 1.8159 high-strength steel. Seat: 1.4571 (AISI 316Ti) stainless steel.
ARI SAFE P 35.921 Safety Valve — Technical Specifications
It finds widespread use in steam installations, power plants and the chemical industry. In addition, it provides pressure control in hot water and steam circuits of HVAC systems. In this context, the DN32 nominal diameter and PN40 pressure class offer safety in high-flow lines. Moreover, a maximum operating temperature of 450 °C ensures durability under demanding process conditions.
Key Advantages
- Proportional lift principle prevents sudden pressure shocks and provides precise control
- 1.0619+N cast steel body and stainless steel internals deliver high corrosion resistance
- PN40 pressure class and 450 °C temperature tolerance ensure safe operation in demanding industrial conditions
Applications
- Steam installations: pressure safety in boilers, steam lines and condensate systems
- Power plants: safety control in high-temperature and high-pressure lines
- Chemical and petrochemical industry: safety in process lines carrying aggressive fluids
Consequently, the ARI SAFE P 35.921 Safety Valve is one of the indispensable safety devices of industrial facilities with its high safety standards and durable material structure. ORFA Industrial supplies worldwide and provides technical support.
