ARI CHECKO-V 23.003 Lift Check Valve PN25 DN32

ARI CHECKO-V 23.003 Lift Check Valve PN25 DN32

Reliable reverse flow protection for high-pressure and high-temperature lines.

The ARI CHECKO-V 23.003 Lift Check Valve PN25 DN32 is a valve solution that safely prevents reverse flow in piping systems. In addition, its ductile iron body and stainless steel disc withstand demanding conditions. It is therefore preferred especially in steam and hot water lines. Furthermore, the flanged connection type makes installation easy.

This product works on the lift check valve principle, lifting the disc upward to allow flow when pressure builds in the flow direction. Consequently, when flow stops, the spring and gravity close the disc quickly. In this way, reverse flow is fully blocked and system safety is ensured. The body and cover use EN-JS1049 ductile iron, the disc uses 1.4021+QT (AISI 420) stainless steel, and the spring uses 1.4310 (AISI 302) stainless steel.

ARI CHECKO-V 23.003 Lift Check Valve — Technical Specifications

This check valve is used in critical areas such as power plants and petrochemical facilities. In particular, it is ideal for preventing reverse flow at pump outlets. Moreover, it operates safely in industrial process lines and heating systems. Furthermore, it offers high performance with a 350°C temperature and PN25 pressure rating.

As a result, the ARI CHECKO-V 23.003 Lift Check Valve is a long-lasting and reliable backflow prevention solution for industrial piping. ORFA Industrial supplies worldwide and provides technical support.
